Live demo
Open the side panel on this page and try every feature with the demo targets below — no recordings, the canvas is the real thing.
Open the side panel to begin
Get started
Design Mode is a Chromium extension that turns any website into a live design surface. Edit layout, type, colour, and structure with visual controls — then ship the result to your AI coding agent.
First time? Pin the extension to your toolbar so it's always one click away. Then use the keyboard shortcut Alt+D (Option+D on macOS) to open the side panel on this page.
Try itPin Design Mode in your Chrome toolbar, then press Alt+D on this page. The side panel should open on the right.
Inspector mode
The crosshair icon at the top of the side panel toggles inspector mode. Hover any element on the page and you'll see a yellow outline; click to select it and the Design tab fills with that element's properties.
Hovering shows the layer in the panel's indicator chip as 'Hovering'. Clicking flips it to 'Selected' and locks the focus on that layer.
Try itClick the crosshair in the side panel header, then hover over the card below. Click the card to select it.
Hover me. Then click me.
I'm a generic card waiting for you to pick me. Selecting locks the focus on me until you click somewhere else.
Layers panel
The Layers tab shows the page's DOM as a tree. Search by tag, class, id, or smart name. Drag layers to reorder them. Toggle visibility with the eye icon. Multi-select to apply edits to several layers at once.
Each row shows: indentation guide, drag handle, expand/collapse chevron, tag icon, smart name, and a hover-revealed eye toggle.
Try itSwitch to the Layers tab. Try the search input — type 'card' or 'demo'. Drag-reorder one of the list items below.
- List item one — drag me
- List item two
- List item three
- List item four
Design panel
The Design tab is where you edit a selected layer's properties. It mirrors Figma's section order — Position → Layout → Appearance → Typography → Fill → Stroke → Effects — so the mental model carries over.
Sections only render for relevant layer kinds: Typography appears on text layers, Layout hides for media, etc. The next 8 sub-sections walk through each.
Indicator + Icon + Media
At the top of the Design tab, the indicator chip shows what's currently focused: 'Selected' (blue), 'Hovering' (yellow), or 'Page' (when no specific layer is picked). The CSS button next to it opens a computed-CSS overlay for the selection.
When you select an SVG icon from a known library (Lucide, FontAwesome), an Icon section appears so you can swap to a different icon in the same library. When you select an image / video / SVG element, a Media section appears with a preview, src, fit, alt, and a one-click Download button.
Try itPick the heart icon and the photo below. Notice the Icon and Media sections appear above Position. Click the Download button on the photo.
Position
Position handles where a layer sits inside its parent: position type (static / relative / absolute / fixed / sticky), object alignment, X/Y/Z, rotation, flip, and 3D transforms in Advanced.
Try aligning the card to the right edge using the alignment buttons. Try rotating it 90° with the quick-rotate icon. Try flipping it horizontally.
Try itSelect the card below. In Position, click 'Align right', then 'Rotate 90° clockwise', then 'Flip horizontally'.
Position me
Use the alignment buttons in Position to pin me.
Layout
Layout is for sizing and child arrangement. The 4-mode segmented switches between block, horizontal stack (flex row), vertical stack (flex column), and grid. Below it: W/H, aspect ratio lock, padding/margin nested box, gap, and the 9-cell children-align pad.
Switching to Grid auto-prefills a 1fr 1fr template so you see the change immediately.
Try itSelect the container below. Switch its Layout mode from Free to Horizontal stack, then to Grid. Try the children-align pad to push items around.
A
B
C
D
Appearance
Appearance covers opacity, blend mode, corner radius, and the color-adjust filters (brightness, contrast, saturate, hue-rotate, grayscale, invert, sepia).
The corner radius has a primary input + a scan toggle that expands a 2×2 grid for individual corners. Click the scan icon and try unequal corners.
Try itSelect the card below. In Appearance, click the scan icon next to Corner radius, set the top-left corner to 24px and the bottom-right to 0.
Pick me. Tweak my opacity, blend mode, and corner radius.
Typography
Typography is shown for text-bearing layers (h1-h6, p, span, a, button, label, …). Pick from page-discovered fonts, set weight, size, line-height, letter-spacing, color. Toggle bold / italic / underline / strikethrough. Choose case, alignment, and list style.
Try itSelect the heading below. Bump the size to 32px, try changing case to UPPERCASE, then back to none. Set letter-spacing to 0.04em.
Sample heading
Pick this paragraph and try changing the line-height, letter-spacing, weight, or font family.
- Bulleted item one
- Bulleted item two
- Bulleted item three
Fill
Fill is multi-layered. Add a solid color, a gradient (linear / radial / conic), or an image as separate stacked layers. Each layer has its own size / repeat / position / blend mode in the per-layer settings.
Try itSelect the hero block below. Click '+ Add fill' → Linear gradient. The gradient stacks on top of the existing solid.
Fill me
Add a linear gradient on top of my solid background.
Stroke
Stroke supports Inside / Outside / Center positioning. Color, weight, full CSS border-style dropdown (solid, dashed, dotted, double, groove, ridge, inset, outset, hidden, none, plus auto for browser focus rings), and per-side widths via the settings-2 icon.
Picking 'dashed' opens a dashed config panel: dash, gap, and cap (square / round) — stored as design tokens for code generation.
Try itSelect the square below. In Stroke, set color to red, weight 2, position Outside. Then switch to Inside to see how the stroke moves.
No stroke yet
Effects
Effects is a Figma-aligned six-kind layered list: Inner shadow, Drop shadow, Layer blur, Background blur, Noise (Mono / Duo / Multi), and Texture. Each row drags to reorder, hides via the eye, and removes via the trash.
Drop shadow is one row spanning three CSS chains — the 'Show behind transparent areas' checkbox swaps between box-shadow (rectangle), text-shadow (alpha-bound to glyphs on text elements), and filter:drop-shadow (alpha-bound to the whole element shape). Spread is preserved when toggled off and re-emitted when toggled back on.
Noise renders via SVG-data-URI background overlays on a ::after pseudo-element so it doesn't disturb layout; Texture works the same with an optional 'Clip to shape' that inherits the element's border-radius and clip-path.
Try itSelect the floating card below. Click the + in the Effects header, then 'Drop shadow'. Toggle the 'Show behind transparent areas' checkbox to see how the shadow swaps between rectangle and alpha-bound rendering. Then add Noise → Mono and watch the grain land.
Drop a shadow on me
Motion
Split out from Effects into its own section — Transition, Animation, Transform, Motion path, View transition, Scroll-driven animation. Each editor surfaces every CSS longhand the relevant property exposes, plus a Preview button for transitions and animations.
The section starts collapsed by default so the design tab stays compact; expand the chevron next to 'Motion' in the side panel to use it.
Try itSelect the floating card. Expand Motion. Click + → 'Transition', set duration 0.3s, then change the card's background colour — watch it ease into the new value. Click + → 'Animation' and pick a built-in dm-fade-in keyframe to preview a one-shot animation.
Animate me
Pick me, expand Motion, add a Transition on background-color or transform, then hover this card.
Layout guide
Figma-style overlay of Columns / Rows / Grid bars on the selected element. Renders as a ::before pseudo-element so it doesn't touch layout; per-element session memory means the bars stay configured when you reselect the element.
Each row carries a kind dropdown, count (or cell size for Grid), settings expand, eye, and trash. Settings opens a 3×2 grid for Columns/Rows (Colour + Opacity / Align + Size / Margin + Gutter) or 1×2 for Grid (Colour + Opacity). The section header's eye toggles every guide on the element without losing the row config.
Try itSelect the full-width container below. Open Layout guide → click Add → keep Columns kind, count 12, default 10% red. Toggle the section eye to hide and re-show the overlay. Drag to add a second guide row for Rows.
Wide container — apply a Columns × 12 layout guide on me.
Presets
Open with the bookmark icon in the action row. Presets covers all nine Design-tab sections (Position / Layout / Appearance / Typography / Fill / Stroke / Effects / Motion / Layout guide), with one preset seeded per kind so the JSON export shows the full schema.
Save the currently-selected element's relevant CSS properties under a name + kind. Apply any saved preset back to a different element with one click. Edit a preset to rename / change properties / drop fields. Delete (with confirmation) to remove. Import / Export bring presets to a JSON file for sharing.
Try itOpen the bookmark icon. Browse the seeded presets — apply 'Headline 1' to a heading on the page, then save the current card's styles as a new 'Card · Soft' preset under the Effects kind.
Changes panel
Every edit is tracked in the Changes tab — grouped by element with friendly group labels (preset / multi-select / visibility) when one action touched many properties at once. The 'View Original' / 'View Changes' toggle previews the page with or without your edits.
Per-change actions: Revert (trash icon, actually reverses the change on the page), Batch apply (zap icon, applies the change to all matching elements with a count badge ×N). Clear All wipes everything in one click.
Try itSwitch to the Changes tab after making edits in the previous sections. Click 'View Original' to flip back. Try Batch apply (zap) on a style change.
Action row
Above the tabs sits a row of contextual buttons: Parent / Child (DOM navigation), Duplicate / Remove, Comment, Pause animations, Screenshot, Presets, Undo / Redo. Most need a layer to be selected; Pause / Screenshot / Presets / Undo / Redo are always available.
Try itTry the Pause icon in the action row — the animated badge below should freeze. Click again to resume.
✦ pulsing badge
Settings
Click the gear icon in the panel header to open Settings. Pick your color format (HEX / RGB), capture mode for screenshots (clipboard / download / both), and toggle MCP auto-connect.
Try itOpen Settings. Switch the color format from HEX to RGBA. Notice how color values in the Design tab re-render in the chosen format.
Theme
The side panel has its own theme (light / dark / system) — independent of the page you're editing. The theme switcher in the panel header cycles through the three.
System mode follows your OS dark-mode setting and updates live when it changes.
Try itClick the moon / sun icon in the panel header to flip between dark and light themes.
MCP server
Design Mode ships with an optional MCP companion that bridges the extension to your coding agent (Claude Code, Cursor, etc.) over a local WebSocket. With MCP running and an agent connected, your changes can be sent live with one click instead of being copied through the clipboard.
Start it from the repo root with npm start. The panel header indicator turns green when an agent is connected.
Try itFrom the repo root: `npm start --prefix packages/mcp-local`. In the panel header, watch the MCP indicator flip from offline (grey) to running (yellow) to connected (green) once your agent attaches.
Copy Prompt
At the bottom of the side panel, Copy Prompt builds a markdown summary of every tracked change — element selectors, before/after CSS, text edits, DOM operations, and any comments — and copies it to the clipboard. Paste into your agent or chat of choice.
When source detection finds a React component, the prompt also includes a file:line hint so the agent can land on the right source.
Try itAfter making a few edits in this demo, click Copy Prompt at the bottom of the panel. Paste into a text editor to see the markdown payload.
Send to Agent
Send to Agent pushes the same Copy Prompt payload directly to a connected coding agent over MCP — no clipboard round-trip. Enabled when MCP is running AND an agent is connected. The button's tooltip names the specific blocker if either is missing.
This is the fastest path from 'I just designed it in the browser' to 'the source code is now updated'.
Haven't set up an agent yet? The MCP tour walks you through all three connection modes (Local, Cloud, Self-hosted) with copy-paste config snippets for Claude Desktop, Cursor, and Claude Code — `Set up your agent →` link below.
Try itWith MCP running and your agent attached, click Send to Agent. The agent receives a structured message with every change in this demo session.
